MILLS 144F Mini Cable G652D 200u Black (5.4mm) 4000m

MILLS 144F Mini Cable G652D 200u Black (5.4mm) 4000m

https://www.circonegypt.com/web/image/product.template/366/image_1920?unique=79cce2f

75427/4KM
Cable consists of stranded core with central strength element (FRP) and gel filled loose tubes with optical fibers. Stranded core is fixed by water swellable yarns. Outer sheath is made of polyamide PA12.
Color of outer sheath is black.

75427/4KM
Cable consists of stranded core with central strength element (FRP) and gel filled loose tubes with optical fibers. Stranded core is fixed by water swellable yarns. Outer sheath is made of polyamide PA12.
Color of outer sheath is black.

$ 18,165.00 18165.0 USD $ 18,165.00

This combination does not exist.

Contact Us





Title of the document

Data Sheet Click To Open.

Cable consists of stranded core with central strength element (FRP) and gel filled loose tubes with optical fibers. Stranded core is fixed by water swellable yarns. Outer sheath is made of polyamide PA12.

Color of outer sheath is black.

Design
Number of optical fibres in cable 144
Number of loose tubes 6
Number of optical fibres per loose tube 24
Diameter of CSM, mm 1.6
Loose tube diameter, mm 1.5
Outer sheath thickness, mm 0.4
Cable diameter, mm 5.4
Cable Length 4000 metres (4 Kilometres)
Cable weight, kg/km 18.7

Optical Fibre
Fibre type <<U>>
Fibre Brand Corning
SMF 28®ULTRA, SMF 28+®BB
ITU-T Recommendation G.652D + G.657.A1
Dimensional Specifications
Core-Clad Concentricity 0.5µm
Cladding Diameter 125±0.7µm
Cladding Non-circularity 0.7%
Coating Diameter 200±5µm


​
